FLYGT C3501 - Tools

Property
class
M4 M5 M6 M8 M10 M12 M16 M20 M24
Stainless steel, A2
and A4, torque Nm
(ft-lbs)
70 +80
5
1.2 (0.9) 2.7 (2) 5.4 (4) 9.3 (6.9) 22 (16) 44 (32) 76 (56) 120 (88) 187 (138)
Carbon steel and
alloyed steel, torque
Nm (ft-lbs)
8.8 2.3 (1.7) 4.6 (3.4) 7.8 (5.8) 19 (14) 38 (28) 65 (48) 158 (116) 308 (228) 532 (392)
10.9
3.2 (2.4) 6.5 (4.8) 11(8) 26 (19) 52 (38) 91 (67) 222 (164) 433 (320) 748 (552)
12.9
3.9 (2.9) 7.8 (5.8) 14 (10.3) 32 (23.6) 63 (46) 109 (80) 266 (196) 519 (383) 896 (661)
Tools
Service guide
The service guide is a search engine for pump part numbers and spare parts. The service guide is available
at www.itt.com. For a valid password, contact flygtpumpar@flygt.com.
Tools
Beside ordinary tools, the following tools are required in order to preform the necessary maintenance of
the pump.
Part no Denomination Range of use
83 95 42 Oil drainage pumps Drainage pumps for emptying oil
housing
84 13 68 Hydraulic unit
Table 22: R3231
Part no Denomination Range of use
436 19 00 Basic kit II
436 74 00 Impeller tool
Table 23: C3300/6X5 LT
Part no Denomination Range of use
84 20 49 Puller
479 23 00 Extension
479 25 00 Washer
Table 24: C3300/6X5 MT
Part no Denomination Range of use
400 54 03 Dismount./lifting tool (for imp.
x41, x42)
400 54 05 Dismount./lifting tool (for imp.
x32)
Table 25: C3300/6X5 HT
Part no Denomination Range of use
81 39 63 Screw (3 pcs)
491 74 00 Puller unit
Table 26: C3231, C3306, C3356
Part no Denomination Range of use
432 43 00 Washer (included in basic kit II)
436 19 00 Basic kit II
436 74 00 Impeller tool
582 65 00 Stand unit
588 92 00 Washer unit Mounting the locking assembly
Maintenance
102 C3300/6x5, C/R3231, C3240, C3306, C3312, C3351, C3356, C3400, C3501, C3531, C3602, C3800 Installation,
Operation and Maintenance Manual
