3. Check the paint; if damaged, repaint.
Horizontal lifting
Two sets of lifting equipment must be used to lift the pump for repair work.
The drive unit must never be placed on the shaft unit or the impeller/propeller. Damage to the impeller/
propeller, seals or bearings can result from placing the drive unit on the impeller/propeller or shaft.
Use the following method to lift the pump in the horizontal position.
Figure 44: Drive units 605–775
Figure 45: Drive units 805–995
Maintenance
C3300/6x5, C/R3231, C3240, C3306, C3312, C3351, C3356, C3400, C3501, C3531, C3602, C3800 Installation,
Operation and Maintenance Manual
89
