1. Coolant
2. Seal flushing, inlet
3. Pumped fluid, inlet
4. Pumped fluid and seal flush water, outlet
Applications for seal flushing
Examples of demanding applications where seal flushing might be used include the following:
• Corrosive liquids
• Water containing excessive amounts of sand, fine sediment or other abrasive material
• Water containing calcium deposits
• Water containing excessive amounts of fibers or other materials with a tendency to clog together.
For more information regarding seal flushing applications please contact your ITT representative.
Circuit diagram for seal flushing
The supply of incoming flushing water should be arranged as described in the circuit diagram below. As all
slushing water is lost into the hydraulic end, this is always an open circuit solution.
Product Description
C3300/6x5, C/R3231, C3240, C3306, C3312, C3351, C3356, C3400, C3501, C3531, C3602, C3800 Installation,
Operation and Maintenance Manual
41
