Connect the seal flushing
This instruction is for connecting the seal flushing water to the pump, in applications where seal flushing is
used.
1. Check that the supply of incoming seal flushing water has been arranged as shown in Circuit diagram for
seal flushing (page 41).
2. Connect the seal flushing supply water to the pump.
See Connections for seal flushing (page 43).
Check the impeller rotation
WARNING:
The starting jerk can be powerful.
1. Start the motor.
2. Stop the motor after a few seconds.
3. Check that the impeller rotates according to this illustration.
The figure shows a generic impeller pump.
Installation
C3300/6x5, C/R3231, C3240, C3306, C3312, C3351, C3356, C3400, C3501, C3531, C3602, C3800 Installation,
Operation and Maintenance Manual
77
