Lift pump from horizontal position and remove transport pallet
WARNING:
• An assembled pump must never be lifted by the holes in the hydraulic unit.
• Stay clear of suspended loads.
NOTICE:
• When handling the pump to and from horizontal position, the pump should always be lifted by the
lifting link. Use a suitable lifting sling/strap.
Lift with single-hook equipment
1. Fasten a suitable lifting sling/strap to the lifting eye on the top of the drive unit.
See Lifting (page 11).
2. Raise the pump approximately halfway to its upright position.
The pump is still be attached to the transport pallet.
3. Slide a pallet or similar object under the inlet section.
This will minimize the jolt which may occur later in the lifting, when the pump is almost fully upright.
Transportation and Storage
14 C3300/6x5, C/R3231, C3240, C3306, C3312, C3351, C3356, C3400, C3501, C3531, C3602, C3800 Installation,
Operation and Maintenance Manual
