For C3231: Make sure that the support columns on C3231 are outside the pallet, as they may break if
used as support when raising. See figure below.
4. Continue raising the pump until it is in an upright position.
The pump may jolt or sway near the end of the lifting operation.
WARNING:
Keep a safe distance while the unit is moving.
5. Remove the straps holding the pump to the transport pallet.
Transportation and Storage
C3300/6x5, C/R3231, C3240, C3306, C3312, C3351, C3356, C3400, C3501, C3531, C3602, C3800 Installation,
Operation and Maintenance Manual
15
