FLYGT C3501 - Remove the Locking Assembly

Pump Action
C3240,
C3312,
C3351,
C3400,
C3501,
C3531,
C3602 or
C3800
Remove the impeller screw. Insert the puller screw 576 84 00 in the thread of the
impeller-sealing washer (C) to remove the washer.
C
Figure 47: C3240, C3312, C3351, C3400, C3501, C3531, C3602 or C3800
The locking assembly is now accessible for removal.
Remove the locking assembly
1. Remove the locking assembly:
Maintenance
94 C3300/6x5, C/R3231, C3240, C3306, C3312, C3351, C3356, C3400, C3501, C3531, C3602, C3800 Installation,
Operation and Maintenance Manual
