1. Tee, nipple (if needed)
2. Shutoff valve
3. Pipe to drain coolant
Figure 8: P, S, and T installations with external cooling
Product Description
C3300/6x5, C/R3231, C3240, C3306, C3312, C3351, C3356, C3400, C3501, C3531, C3602, C3800 Installation,
Operation and Maintenance Manual
39
