23. Product number
24. Country of origin
Figure 10: The drive unit plate
Hydraulic unit
1
2
3
4
5
689 710
11
12
13
1. Serial number
2. Product code + Number
3. Read installation manual
4. Impeller diameter
5. Propeller blade angle
6. Product weight
7. Direction of rotation: L=left, R=right
8. Impeller code
9. Rated speed
10. Pressure class
11. Column diameter/Inlet and outlet diameter
12. Product number
13. Country of origin
Figure 11: The hydraulic unit plate
Product Description
44 C3300/6x5, C/R3231, C3240, C3306, C3312, C3351, C3356, C3400, C3501, C3531, C3602, C3800 Installation,
Operation and Maintenance Manual
