12
MFR-16MV cards can also be installed to the router. A single MFR-16MV card provides 16
outputs (using two slots) and supports two multiview channels. To output multiview images, a
multiview channel (MV OUT1 or MV OUT2) needs to be directly assigned to output ports.
Instead of multiview images, you can also assign any destination channel to output ports as a
single image.
12G-SDI Signal Routing
12G-SDI signal routing is enabled by installing MFR-8SDIGB and MFR-8SDOGB cards and
using them for 12G-SDI input/output. (If using MFR-8SDIGB and MFR-8SDOGB for 3G-SDI
input/output, the “Standard SDI Signal Routing” table in the previous page applies.)
The number of installed MFR-8SDIGB and MFR-8SDOGB cards determines the matrix size.
(16 x 18 to 2 x 2)
Number of cards: MFR-8SDOGB (12G-SDI output)
9
8
7
6
5
4
3
2
1
Number of
cards
MFR-8SDIGB
(12G-SDI
input)
8
16 x 18
16 x 16
16 x 14
16 x 12
16 x 10
16 x 8
16 x 6
16 x 4
16 x 2
7
14 x 18
14 x 16
14 x 14
14 x 12
14 x 10
14 x 8
14 x 6
14 x 4
14 x 2
6
12 x 18
12 x 16
12 x 14
12 x 12
12 x 10
12 x 8
12 x 6
12 x 4
12 x 2
5
10 x 18
10 x 16
10 x 14
10 x 12
10 x 10
10 x 8
10 x 6
10 x 4
10 x 2
4
8 x 18
8 x 16
8 x 14
8 x 12
8 x 10
8 x 8
8 x 6
8 x 4
8 x 2
3
6 x 18
6 x 16
6 x 14
6 x 12
6 x 10
6 x 8
6 x 6
6 x 4
6 x 2
2
4 x 18
4 x 16
4 x 14
4 x 12
4 x 10
4 x 8
4 x 6
4 x 4
4 x 2
1
2 x 18
2 x 16
2 x 14
2 x 12
2 x 10
2 x 8
2 x 6
2 x 4
2 x 2
AUDIO Signal Routing
The number of installed audio cards: MFR-8SDI
(*1)
, MFR-8AAI, MFR-8AAO, MFR-8AESI,
MFR-8AESO, MFR-8MADIPO and MFR-8AESPO determines the matrix size.
(The matrix sizes below do not indicate the number of audio channels, but the number of
streams. Use the followings to find the number of audio channels: SDI embedded: 16 channels,
AES/EBU: 2 channels, Analog: 2 channels, MADI: 64 channels)
Number of cards: MFR-8AAO, MFR-8AESO, MFR-8MADIPO or MFR-8AESPO
9
8
7
6
5
4
3
2
1
Number of
cards:
MFR-8SDI
MFR-8AAI
MFR-8AESI
8
64 x 72
64 x 64
64 x 56
64 x 48
64 x 40
64 x 32
64 x 24
64 x 16
64 x 8
7
56 x 72
56 x 64
56 x 56
56 x 48
56 x 40
56 x 32
56 x 24
56 x 16
56 x 8
6
48 x 72
48 x 64
48 x 56
48 x 48
48 x 40
48 x 32
48 x 24
48 x 16
48 x 8
5
40 x 72
40 x 64
40 x 56
40 x 48
40 x 40
40 x 32
40 x 24
40 x 16
40 x 8
4
32 x 72
32 x 64
32 x 56
32 x 48
32 x 40
32 x 32
32 x 24
32 x 16
32 x 8
3
24 x 72
24 x 64
24 x 56
24 x 48
24 x 40
24 x 32
24 x 24
24 x 16
24 x 8
2
16 x 72
16 x 64
16 x 56
16 x 48
16 x 40
16 x 32
16 x 24
16 x 16
16 x 8
1
8 x 72
8 x 64
8 x 56
8 x 48
8 x 40
8 x 32
8 x 24
8 x 16
8 x 8
(*1) Used as MADI input card.
