80
Multiviewer
MFR-16MV
16 SDI output card with multiviewer function (Up to 4 cards)
- 2 slots required per card
- 75-ohm BNC x 16
Reference Input
BB: 0.429 Vp-p (NTSC)/0.45 Vp-p (PAL) or Tri-level Sync: 0.6 Vp-p
75-ohm BNC x 1, loop-through (Terminate with 75-ohm BNC
terminator, it unused.)
Interfaces
MFR-LAN
10/100Base-TX, RJ-45 x 2
(For connecting up to 128 RU/GPI units.)
(Second LAN port used in redundant CPU configuration)
PC-LAN
10/100/1000 Base-T, RJ-45 x 2 (For PC and external device operation)
(Second LAN port used in redundant CPU configuration)
ALARM
9-pin D-sub (female) x 1
(Power alarm, fan alarm, crosspoint error, CPU changeover and
secondary CPU error)
9-1-2. MFR-GPI
Basic specifications
Temperature/Humidity
0 to 40 / 30% to 85% (no condensation)
Power
+12VDC pin connector x 2 (redundant power supply in standard
configuration)
Consumption
100 V AC to 120 V AC: 8 VA (4 W)
220 V AC to 240 V AC: 13 VA (6 W)
Dimensions
430 (W) x 44 (H) x 110 (D) mm EIA 1 RU
480 (W) (Including rack mount brackets)
Weight
2 kg
Consumables
AC adapter: Replace every 5 years
Technical specifications
Number of connections
Max. 4 (MFR-GPI units only)
Max. 128 (including Main, MFR-RU Series, MFR-GPI and MFR-TALM
units)
Interface
MFR-LAN
10/100BASE-TX RJ-45 x 1
(Ethernet hub is needed for Main and multiple units connections.)
SERVICE
RS-232C: 9-pin D-sub (male) x 1 (for maintenance)
GPI IN/TALLY OUT
37-pin D-sub (female) x 4
128-input/output (user assignable)
SERIAL 1-4
RS-232C/422 (selectable): 9-pin D-sub (male) x 4
