62
Ex. 2) When Source 113 is selected for Destination 49 in Levels 2 to 7: (Function )
(A)
@ X:123456/30,70[CR]
[CR][LF]>
(B)
[CR][LF]
C:123456/30,70...S5:IA[CR][LF]
(C)
[CR][LF]
S:130,70[CR][LF]
(C)
[CR][LF]
S:230,70[CR][LF]
(C)
[CR][LF]
S:330,70[CR][LF]
(C)
[CR][LF]
S:430,70[CR][LF]
(C)
[CR][LF]
S:530,70[CR][LF]
(C)
[CR][LF]
S:630,70[CR][LF]
* [CR] and [LF] represent Carriage Return (0x0D) and Line Feed (0x0A) respectively.
7-3-2. Receiving Responses (Commands 1-6)
Timeout Waiting for Command Response from MFR
Set the timeout period (maximum permitted time until its response returns from the MFR
unit) to 1 second for short message commands and to 5 seconds for long message
commands.
If Sending Commands Successively:
-For X:”, B:C”, P: and W: commands, send the next command after a prompt
returns.
-For S?”, X?, P?”, “V?”, B:Eand Z: commands, send the next command after a
prompt and reply messages return.
-For S?” and ”Z:commands as well as V?” and B:E” commands after executing many
preset commands, send the next command after having finished receiving all strings of
reply messages.
Ex. 1)
Allows to send the next command when receiving a prompt.
Resends the previous command when the timeout period (5 seconds) have elapsed without
reply after sending a command.
Ex. 2)
Allows to send the next command when receiving a prompt.
Resends the previous command when the timeout period (5 seconds) have elapsed without
reply after sending a command.
Recognizes and uses “S” responses as tallies (crosspoint states).
Ex. 3)
Allows to send the next command when receiving a prompt.
Recognizes and uses “S” responses as tallies (crosspoint states).
Resends the previous command when the timeout period (5 seconds) have elapsed without
reply after sending a command.
Sets the maximum number of continuous resendings, because crosspoints cannot be changed
if they are locked or inhibited to change.
@ X:123456/30,70
>
C:123456/30,70…S5:IA
S:130,70
S:230,70
S:330,70
S:430,70
S:530,70
S:630,70
Terminal display:
