2-4-5. MFR-8SDI (MADI Input)
MFR-8SDI is an SDI or digital audio input card.
When using as an SDI input, refer to Sec. 2-3-1 “MFR-8SDI” for details.
When using as a digital audio input, it can accept 8 MADI signals.
Up to 8 cards can be installed into Slot No. 01 to 08.
See Input /output cards and Slots” in Sec.2-2. "MFR-3100EX Rear Panel."
BNC x 8 inputs (64 audio channels per input) unbalanced 75-ohm
2-4-6. MFR-8MADIPO (MADI/SDI Output)
MFR-16MADIPO is a digital audio/ video output card.
Maps audio input channels in SDI / AES/EBU / MADI streams and outputs as MADI / SDI
signals.
Up to 9 cards can be installed into Slot No. 09 to 17.
See Input /output cards and Slots” in Sec. 2-2 "MFR-3100EX Rear Panel."
BNC x 8 outputs (MADI/SDI x 8) 75-ohm
Supported formats
SDI input
SDI output
3G-SDI
1080/59.94p, 1080/50p
HD-SDI
1080/59.94i, 1080/50i, 1080/29.97PsF, 1080/23.98PsF,
720/59.94p
Audio input (48kHz / 24bit)
MADI (64-channel only), AES/EBU
Audio output (48kHz / 24bit)
MADI (64-channel only)
IMPORTANT
Sampling Rate Converter is not equipped with the card.
Inputting audio should be synchronized with the router REF (reference) input.
The following functions are available and managed by a group of 8 streams.
Mapping
Selects the input type from SDI, MADI (1-32), MADI (33-64) or AES and the output type from
SDI or MADI, and maps audio sources to outputs per physical channel (stream).
Set Mapping in [Web-based Control: Audio Settings page].
If MADI is selected under Output Type, audio sources of last half channels (33-64) cannot be
assigned, but are automatically set according to the input signal type. (See the table below.)
Output Type
Setting
MADI Output
Stream
Input Type Setting
SDI
MADI (1-32)
MADI (33-64)
AES
MADI
First half 32 channels
(Ch 1-32)
Mapped audio source channels
Last half 32 channels
(Ch 33-64)
Muted
33-64 channels of
MADI input
stream
1-32 channels of
MADI input
stream
Muted
2
3
4
5
6
7
8
1
1
IN
1
2
3
4
5
6
7
8
