60
Func.
Control command
Command response
Ref.
5
LOCK ALL units.
@[sp]W:<Lvl>/<Dest>,<ID>,1
W!<Lvl><Dest>,<ID>,1
-
LOCK OTHER units.
@[sp]W:<Lvl>/<Dest>,<ID>,2
W!<Lvl><Dest>,<ID>,2
-
Disable LOCK.
@[sp]W:<Lvl>/<Dest>,<ID>,0
W!<Lvl><Dest>,<ID>,0
-
6
@[sp]Z:<Lvls>
S:<Lvl><Dest>,<Src>
C:<Lvls>/<Dest>,<Src>[…..[S<Number of
crosspoints in Salvo>][L<Number of
Links>]]:I<ID>
-
7
@[sp]K?<SorD><AorK>,<Ofset>
K:<SorD><AorK><No.>,<Dat>
7-3-3
8
@[sp]A?
If CPU is active:
A:<ID>
7-3-4
If CPU is passive:
(No response)
9
@[sp]W?<Lvl>,<Dest>
W!<Lvl><Dest>,<ID>,0-2
7-3-5
10
K:<S or D><S or L or
A><No.>,<Dat>
7-3-6
11
@[sp]F?<Lvl>
F:<Lvl><Dst Size>,<Src Size>/< Dst Size
>,<Src Size>
7-3-7
12
Preset video format, reference
and switching point.
@[sp]UF:<YY>/<R#>,<S$>
UF!<YY>/<R#>,<S$>
7-3-8
Set preset settings.
@[sp]UE:A
UR!W
UR!<YY>/<R#>,<S$>
UR!E(Error response)
Cancel preset settings.
@[sp]UE:C
UR!C
13
@[sp]AA:<SlotNo.><Grp>/<I-
No>,<L-Lvl><L-Src><T#>
AA:<SlotNo.><Grp>/<I-No>,<L-Lvl><L-
Src><T#>
7-3-9
14
@[sp]AX:<SlotNo.><Grp>/<O-
BNC><O-CH>,<I-No.><I-CH>
AC:<SlotNo.><Grp>/<O-BNC><O-CH>,<I-
No.><I-CH>:I<ID>
7-3-10
15
@[sp]AL:<ONorOFF>
AL:<ONorOFF>
7-3-11
16
Preset video format and delay.
@[sp]AF:<SlotNo.><Grp>/<FORMA
T>,<D#>
AF!<SlotNo.><Grp>/<FORMAT>,<D#>
7-3-12
Set preset settings.
@[sp]AE:A
AR!W
AR!<SlotNo.><Grp>/<FORMAT>,<D#>
AR!N (Error response)
Cancel preset settings.
@[sp]AE:R
AR!R
* [sp] indicates a space.
* Commands must end with a carriage return (ASCII code 0x0D) only or carriage return and line feed
(ASCII code 0x0A). MFR units add a carriage return and line feed in front of and at the end of reply
messages.
Command parameters and setting range
<Lvl>
0 - 7
Allows you to specify the level to switch crosspoints.
* When in single-level operation.
<Lvls>
0 - 7
Allows you to specify the levels to switch crosspoints.
* When in multiple-level operation
<Dest>
000 - 1FF
Allows you to specify the crosspoint switchover destination.
<Src>
000 - 3FF
Allows you to specify the source of crosspoint switchover.
<ID>
0 - FE
Unit ID. The ID must be different from that of other devices in the
same network. Use 1 to FE for ID numbers. The host returns 0 when
the lock is released.
* All command values are in hexadecimal, starting from 0 (zero).
(For example, Source “16” is represented as <Src>”F.”)
* If levels are not in use, set <Lvl> or <Lvls> to 0”(zero).
