58
 MFR-16AAOEX
 MFR-8AAO
Parameter
Description
Audio
Output
Mute
Allows you to turn Mute ON/OFF.
Level
Allows you to set the signal level for the analog output.
(Setting range: -10 dB, 0 dB, 4 dB, 8 dB)
Gain
Allows you to set the gain for the analog output.
(Setting range: -20 dB to 20 dB)
* However, for an 8 dB level setting, the setting range is -20 dB to
16 dB, since the maximum output signal level is 24 dB.
