2-3. PC Network Settings
MFR series factory default port settings are as follows.
 MFR-5000/8000
IP address
MFR-LAN
(or TO RU)
192.168.1.10 (CPU CARD1)
192.168.1.11 (CPU CARD2)
(with an optional MFR-CPU installed)
PC-LAN
(or TO PC)
192.168.1.12 (CPU CARD1)
192.168.1.13 (CPU CARD2)
(with an optional MFR-CPU installed)
Subnet mask
255.255.255.0
 MFR-1616/ 1616R/ 3216/ 3216RPS / 3232/ 3232RPS / 1616A
IP address
MFR-LAN
(or TO RU)
192.168.1.10 (MAIN CARD)
192.168.1.11 (when an optional MFR-SRCPU is installed)
PC-LAN
(or TO PC)
192.168.1.12
Subnet mask
255.255.255.0
 MFR-3000
IP address
MFR-LAN
192.168.1.10 (MAIN CARD)
192.168.1.11 (requires MFR-30CPU option)
PC-LAN
192.168.1.12
MFR-30FP
192.168.1.1 (Fixed) (MFR-30FP option)
Subnet mask
MFR-30FP
 MFR-1000
IP address
MFR-LAN
192.168.1.10
PC-LAN
192.168.1.12
Subnet mask
255.255.255.0
After September 2011, the connector labels on MFR Series Routing Switchers have changed from
TO RU and TO PC to MFR-LAN (CPU1, 2) and PC-LAN, respectively.
 MFR-TALM
IP address
MFR-LAN
192.168.1.60
PC-LAN
192.168.1.62
Subnet mask
255.255.255.0
IMPORTANT
Make sure the PC IP addresses and above IP addresses do not conflict. Also make sure the unit
IP addresses do not conflict with IP addresses on the network.
Connect MFR-LAN (or TO RU) and PC-LAN (or TO PC) in separate networks (use a switching
hub, or divide the network into separate segments).
