64
5-6-1-6. Alarm
Selects the alarm reset method.
None: No alarm reset (Alarms are cleared when video is recovered.)
Manual: Uses Reset Now on the GUI to reset alarms.
Time: Alarms are reset when the set time (Reset Time) has passed.
Sets the alarm duration time if Reset Mode is set to Time. After that time
alarms are reset.
Enables / disables alarms for each window.
Resets alarms if Reset Mode is set to Manual.
5-6-1-7. Other Settings
Sets the multiview video output format.
To change to 4K mode, press the 4K button.
Sync: Applying input signal that is synchronized to external
reference signal.
Async: Applying asynchronous input signal. (Some functions are
limited. See Sec. 5-6-3 and Sec. 5-6-4-5.)
If checked, a grid is displayed on the layout workspace.
If checked, windows can be snapped to the grid when they are dragged
on the workspace.
