Framery 2Q Huddle
3. Hold the hex key against the resistance and insert the lock pin into the hole on the left-
hand side of the hinge close to the door frame.
Note: To insert the lock pin, align the hole in the inner cylinder of the hinge with
the hole in the outer surface.
4. Remove the hex key.
Note: Do not remove the lock pin. It holds the spring in place so it does not
unwind and break.
Installation instructions
