Framery 2Q Huddle
2. Install the cable holders with 3.5x16 screws (6 pcs) into the holes in the bottom of the
table top.
Note: Make sure that you remove the cover of the adhesive surface on the
backside of the cable holders.
Note: Make sure that you install the cable holders to the ready-made holes.
3. Remove the M4x6 screw from the lid of the metal box.
130
Installation instructions
