Framery 2Q Huddle
4. Install first the black metal trims to the right-hand side wall with black countersunk 5x50
screws. Then install the back profile of the cord duct and the black metal trims to the
left-hand side wall with black countersunk 5x50 screws.
Use the holes in the black metal trims. They do not match with the holes in the back
profile of the cord duct. You will need to install the screws through the back profile.
Note: Make sure that you install the back profiles in a butt joint in the corner of
the pod.
Note: Make sure that you install the metal trims in a butt joint.
5. Guide the power cord into the cord duct.
Note: Make sure that the power cord is long enough. The recommended
length inside the pod is 3.8 m (12 ft 5 5/8 in).
152
Installation instructions
