Framery 2Q Huddle
5. Install magnets (2 pcs) for the outer edges of the whiteboards. Measure 1150 mm (3
ft 9 ¼ in) from the U-profile seal to the screw hole in the magnet and install with 4x40
screws (2 pcs).
Install the magnets with 15 mm plastic spacers on the wall felt.
Note: Measure the distance from the outer edge of the U-profile seal seal to
the center of the magnet.
Note: Make sure that the outer magnets are level with the inner magnets.
6. Lift the whiteboards onto the brackets.
The lower edges of the whiteboards are held in place by the magnets.
Warning: Lifting requires two people.
180
