Framery 2Q Huddle
2. Install the lower center frame with black M8x50 countersunk screws (2 pcs).
Install the screws from the inside of the pod.
Note: Make sure that the cords are placed in the notch in the lower center
frame and that they are not not pinched.
Note: Do not guide the main power cord in, if you intend to install the power
cord from the roof.
3. Install the lower corner frame of the left-hand side with black M8x50 countersunk
screws (3 pcs).
Note: The seismic support bracket is optional. The maximum size of the
anchor bolt is M10. Follow the local regulations regarding seismic anchoring.
Installation instructions
