Framery 2Q Huddle
5. Install the upper corner frame of the right-hand side with M8x55 bolts (3 pcs) and M8
washers (3 pcs). Use a hand tool to tighten the bolts.
Note: One person holds the glass in place.
Note: Press the acoustic panel aside to reach the bolt holes. Make sure that
you return the acoustic panel to its original position.
6. Install the guide pins (2 pcs).
62
Installation instructions
