Framery 2Q Huddle
1. Peel back the protective plastic approximately 100 mm (4 in) from the top and bottom
of the aluminum frame of the strike plate-side glass.
2. Guide the strike plate-side glass into the grooves and slide it into place.
Note: Make sure that the control panel cord is not damaged during the
installation. You can tape the cord to the aluminum frame to keep it out of the
way.
Note: Make sure that the strike plate-side glass with the strike plate is on the
correct side for the door handing.
Installation instructions
