(3) HOLD indicator
at the end of each welding operation, the actual values for the welding current and
voltage are stored and the Hold indicator lights up.
The Hold indicator refers to the last value reached by the main current I
1
. As soon
as any other welding parameter is selected, the Hold indicator goes off. The Hold
values will continue to be available, however, if welding parameter I
1
is selected
again.
The Hold indicator is cleared when:
- a new welding operation is started
- the welding current I
1
is set
- the mode is changed
- the welding process is changed
IMPORTANT! Hold values are not output if
- the main current phase was never reached,
or
- a pedal remote control was used.
(4) Right digital display
(5) Welding voltage indicator
lights up when parameter I
1
is selected. During welding the current actual value for the welding voltage is
shown on the right-hand digital display.
Before welding, the following appears on the right digital display:
- 0.0 if a TIG welding mode is selected
- 50 V if an MMA welding mode is selected (after a delay of 3 seconds; 50 V is
approximately the average value for the pulsed open circuit voltage)
(6) Unit indicators
m/min indicator
lights up when welding parameter Fd.1 or setup parameter Fd.2 has been
selected
Job N
o
indicator
lights up in Job mode
kHz indicator
lights up when the F-P setup parameter is selected if the value entered for
the pulse frequency >/= 1000 Hz
Hz indicator
lights up when:
- the F-P setup parameter is selected if the value entered for the pulse
frequency < 1000 Hz
- setup parameter ACF has been selected
A indicator
% indicator
lights up when the I
S
, I
2
and I
E
welding parameters and the dcY, I-G and
HCU setup parameters have been selected
s indicator
lights up when the t
up
and t
down
welding parameters plus the following set-
up parameters have been selected:
- GPr
- G-L
- G-H
- SPt
- tAC
- t-S
- t-E
- dt1
- dt2
- Hti
- Ct
- HFt
- Ito
- Arc
