Fuji Xerox DocuPrint C3290 FS

Main Components and Their Functions
2-4
Internal View
Scanner
1. Fuser
2. Print cartridge
3. Transfer unit
4. Button A for opening the front door
1. Duplex unit
1. Automatic document feed cover R
2. Document guides
3. Document feed tray
4. Document glass
5. Scan bar lock switch
1
2
3
4
1
1
3
4
5
2
