Fujitsu Airstage J-II Series User Manual

Note : Specications are based on the following conditions.
Cooling : Indoor temperature of 80°F(26.7°C)DB/67°F(19.4°C)WB,and outdoor temperature of 95.0°F(35°C)DB/75°F(23.9°C)WB.
Heating : Indoor temperature of 70°F(21.1°C)DB/60°F(15.6°C)WB,and outdoor temperature of 47°F(8.3°C)DB/43°F(6.1°C)WB.
Pipe length : 25ft.(7.5 m), Height difference : 0ft.(0 m) (Outdoor unit - Indoor unit).
The protective function might work when using it outside the operation range.
Model name ASUB18TLAV1 ASUB24TLAV1
Power source 1 Phase ~ 208/230V 60Hz
Available voltage range 187 to 253 V
Capacity
Cooling
Btu/h 18,000 24,000
kW 5.3 7.0
Heating
Btu/h 20,000 27,000
kW 5.9 7.9
Input power W 32 60
Fan
Airow rate
High
CFM
(m
3
/ h)
494
(840)
647
(1,100)
Med
453
(770)
536
(910)
Low
406
(690)
430
(730)
Type x Quantity Cross ow × 1
Motor output W 42
Sound pressure
level
High
dB(A)
41 48
Med 39 43
Low 35 35
Heat exchanger
Length in. (mm)
Main: 32-3/16 (817)
Sub: 32-3/16 (817)
Fin pitch FPI
Main: 21
Sub: 18
Rows x Stages
2 × 16
1 × 4 (2 pieces)
Face Area ft
2
. (m
2
) 3.3 (0.31)
Pipe type (Material) Grooved H-pin (Copper)
Fin
Type (Material) Slit (Aluminum)
Surface
treatment
Hydrophilic coating
Air lter
Type Deodorization / Anti-mold
Net material PP monolament net
Enclosure
Material Plastic
Color
White
Approximate color of MUNSELL N 9.25/
Dimensions
(H x W x D)
Net
in. (mm)
12-5/8 × 39-5/16 × 9-3/8
(320 × 998 × 238)
Gross
12-15/16 × 42-15/16 × 16-7/8
(329 × 1,090 × 429)
Weight
Net
lbs. (kg)
33 (15)
Gross 42 (19)
Connection
pipe diameter
Liquid (Flare)
in. (mm)
ø 1/4 (6.35) ø 3/8 (9.52)
Gas (Flare) ø 1/2 (12.70) ø 5/8 (15.88)
Drain hose ø9/16 (13.8) [I.D.]; ø5/8 (15.8) to 11/16 (16.7) [O.D.]
