Note : Specications are based on the following conditions.
Cooling : Indoor temperature of 80°F(26.7°C)DB/67°F(19.4°C)WB,and outdoor temperature of 95.0°F(35°C)DB/75°F(23.9°C)WB.
Heating : Indoor temperature of 70°F(21.1°C)DB/60°F(15.6°C)WB,and outdoor temperature of 47°F(8.3°C)DB/43°F(6.1°C)WB.
Pipe length : 25ft.(7.5 m), Height difference : 0ft.(0 m) (Outdoor unit - Indoor unit).
The protective function might work when using it outside the operation range.
Model name ASUB30TLAV1 ASUB36TLAV1
Power source 1 Phase ~ 208/230V 60Hz
Available voltage range 187 to 253 V
Capacity
Cooling
Btu/h 30,000 34,000
kW 8.8 10.0
Heating
Btu/h 34,000 38,000
kW 10.0 11.2
Input power W 74 103
Fan
Airow rate
High
CFM
(m
3
/ h)
848 (1,440) 954/895 (1,620/1,520)
Med-Hi 706 (1,200) 765 (1,300)
Med 618 (1,050) 659 (1,120)
Low-Hi 553 (940) 577 (980)
Low 524 (890) 524 (890)
Quiet 412 (700) 412 (700)
Type x Quantity Cross ow × 1
Motor output W 61
Sound pressure
level
High
dB(A)
53 55/54
Med-Hi 49 51
Med 45 47
Low-Hi 42 43
Low 39 39
Quiet 33 33
Heat exchanger
Length in. (mm)
Main : 35-7/16 (900)
Sub1 : 35-7/16 (900)
Sub2 : 35-7/16 (900)
Fin pitch FPI Main: 21, Sub1: 18, Sub2: 18
Rows x Stages
Main: 2 × 22
Sub1: 1 × 6
Sub2: 1 × 4
Face Area ft
2
. (m
2
) 4.5 (0.42)
Pipe type (Material) Grooved H-pin (Copper)
Fin
Type (Material) Slit (Aluminum)
Surface
treatment
Hydrophilic coating
Air lter
Type Anti mold
Net material PP plain weave
Enclosure
Material Plastic
Color
White
Approximate color of MUNSELL N 9.25/
Dimensions
(H x W x D)
Net
in. (mm)
13-3/8 × 45-1/4 × 11
(340 × 1,150 × 280)
Gross
15-15/16 × 50 × 17-11/16
(405 × 1,270 × 450)
Weight
Net
lbs. (kg)
40 (18)
Gross 53 (24)
Connection
pipe diameter
Liquid (Flare)
in. (mm)
ø 3/8 (9.52)
Gas (Flare) ø 5/8 (15.88)
Drain hose ø9/16 (13.8) [I.D.]; ø5/8 (15.8) to 11/16 (16.7) [O.D.]
- (04-19) -
