Fujitsu Airstage J-II Series User Manual

Note : Specications are based on the following conditions.
Cooling : Indoor temperature of 80°F(26.7°C)DB/67°F(19.4°C)WB,and outdoor temperature of 95.0°F(35°C)DB/75°F(23.9°C)WB.
Heating : Indoor temperature of 70°F(21.1°C)DB/60°F(15.6°C)WB,and outdoor temperature of 47°F(8.3°C)DB/43°F(6.1°C)WB.
Pipe length : 25ft.(7.5 m), Height difference : 0ft.(0 m) (Outdoor unit - Indoor unit).
The protective function might work when using it outside the operation range.
Model name ASUA7TLAV ASUA9TLAV ASUA12TLAV ASUA14TLAV
Power source 1 Phase ~ 208/230V 60Hz
Available voltage range 187 to 253 V
Capacity
Cooling
Btu/h 7, 5 0 0 9,500 12,000 14,000
kW 2.2 2.8 3.5 4.1
Heating
Btu/h 9,500 10,900 13,500 15,600
kW 2.8 3.2 4.0 4.6
Input power W 17 18 22 34
Fan
Airow rate
High
CFM
(m
3
/ h)
288
(490)
294
(500)
330
(560)
394
(670)
Med
265
(450)
265
(450)
283
(480)
288
(490)
Low
247/218 *
1
(420/370 *
1
)
247/218 *
1
(420/370 *
1
)
247
(420)
247
(420)
Type x Quantity Cross ow × 1
Motor output W 42
Sound pressure
level
High
dB(A)
35 36 39 44
Med 33 33 35 37
Low 31 /27 *
1
31 /27 *
1
31 32
Heat exchanger
Length in. (mm) 23-5/8 (600)
Fin pitch FPI 21
Rows x Stages 2×16
Face Area ft
2
. (m
2
) 2.3 (0.20)
Pipe type (Material) Grooved H-pin (Copper)
Fin
Type (Material) Slit(Aluminum)
Surface
treatment
Hydrophilic coating
Air lter
Type Antibacterial and Mold proong, Ion deodorization
Net material PP honeycomb
Enclosure
Material Plastic
Color
WHITE
Approximate color of MUNSELL N9.25
Dimensions
(H x W x D)
Net
in. (mm)
10-13/16 × 31-1/8 × 8-7/16 (275 × 790 × 215)
Gross 11-7/16 × 32-7/8 × 13-9/16 (290 × 835 × 345)
Weight
Net
lbs. (kg)
20 (9)
Gross 26 (12)
Connection
pipe diameter
Liquid (Flare)
in. (mm)
ø 1/4 (6.35)
Gas (Flare) ø 1/2 (12.70)
Drain hose ø 9/16 (13.8) [I.D.] ; ø 5/8 (15.8) - ø 11/16 (16.7) [O.D.]
*1: This value is "cooling operation / heating operation".
- (04-20) -
INDOOR UNITS INDOOR UNITS

Fujitsu Airstage J-II Series Specifications

General

Brand	Fujitsu
Model	Airstage J-II Series
Category	Air Conditioner
Language	English
