3-4. MINI DUCT TYPE

MODEL: ARUL4TLAV1
ARUL4

Refrigerant pipe are
connection
Liquid ø 1/4 (6.35)

Gas ø 3/8 (9.52)

Drain hose connection Drain hose ø 3/4 (I.D.), ø 1-1/16 (O.D.)
(Drain hose)
Rear view
Top view
Front view
Bottom view
Side view
View A
22-5/8 (575)
6-7/8 (174)
2-1/16
(52)
2–13/16
(72)
6 (153)
11-5/8 (295)
1-3/16 (30)
P3-15/16 (100) × 6
= 23-5/8 (600)
25-9/16 (650)
29-5/8 (752)
1-15/16
(49)
3-3/8 (85)
1-15/16
(49)
2-3/16
(56)
2-5/8
(66)
3-1/16
(78)
6-5/8
(169)
3-5/8
(92)
3/8 (10)
1-3/16
(30)
5-14/16
(150)
7-3/16
(182)
7-5/8
(193)
17-11/16 (450)
7-13/16
(198)
6-5/8
(168)
5-7/8
(150)
3-1/16
(78)
2-1/4
(57)
25-9/16 (650)
26-3/16 (665)
27-9/16 (700)
1-11/16
(43)
1-5/16
(33)
Unit : in. (mm)
