Fujitsu Airstage J-II Series User Manual


MODEL : ARUL18TLAV
A RU L18

Refrigerant pipe are
connection
Liquid ø 3/8 (9.52)

Gas ø 5/8 (15.88)

Drain hose - ø 3/4 (I.D.), ø 1-1/16 (O.D.)
Rear view
View A
Top view
Side view
Front view
Bottom view
(Drain hose)
Drain port
2 (51)
30-1/2 (774)
6-7/8 (174)
2-13/16 (71)
6 (152)
3-7/16 (87)
2-3/16 (56)
33-7/16 (850)
36-3/4 (934)
3-15/16 (100) x 8 = 31-1/2 (800)
1-3/16 (30)
14-13/16 (377)
6-7/16 (163)
4-11/16 (119)
3-1/2 (89)
3-1/16 (78)
2-3/16 (55)
1-7/8 (47)
3/8 (10)
24-7/16 (620)
14-7/16 (367)
10-3/8 (264)
5-11/16 (144)
2-11/16 (69)
33-7/16 (850)
34 (864)
35-7/16 (900)
1-11/16 (43)
1-7/32
(31)
7-13/16 (198)
6-5/8 (168)
5-15/16 (151)
3-1/16 (78)
2-3/16 (55)
Unit : in. (mm)
- (04-36) -
