Fujitsu Airstage J-II Series User Manual

3-6. MEDIUM STATIC PRESSURE DUCT TYPE

MODELS : ARUM24TLAV, ARUM30TLAV, ARUM36TLAV
ARUM24, ARUM30 ARUM36

Refrigerant pipe are
connection
Liquid ø 3/8 (9.52) ø 3/8 (9.52)

Gas ø 5/8 (15.88) ø 3/4 (19.05)

Drain hose - ø 3/4 (I.D.), ø 1-1/16 (O.D.)

Knock out hole (fresh air) - 7-7/8 (200)

Hole for power cable - 7/8 (23)
Unit : in. (mm)
Rear view
Front view
Top view
Side view (R)
Side view (L)
(Drain hose)
Drain port
Drain port
5-7/16 (138) 10-3/8 (264) 10-3/8 (264) 10-3/8 (264)
5-7/16 (138)
3-1/8 (80)
3-1/8 (80)
3-1/8 (80) 3-1/8 (80)
4-Ø1/8 (3.2) (hole)
P.C.D. Ø8-7/8 (225)
Ø8-1/16 (205) (hole)
3-1/4 (82)
2-15/16 (75)
10-5/8 (270)
1-1/4 (32)
Ø7-7/8 (200)
9-7/16 (240)
3-1/8 (80)3-1/8 (80)
6-5/16 (161)
4-Ø1/8 (3.2) (hole)
P.C.D. Ø8-7/8 (225)
3-1/8 (80)
3-1/8 (80)
4-3/4 (121)
Bolt pitch 46-5/16 (1177)
Bolt pitch 18-3/4 (477)
6-13/16 (173)
8-Ø3/16 (5) (hole)
P4-15/16 (125) x 3
= 14-3/4 (375)
P4-15/16 (125) x 3
= 14-3/4 (375)
4-3/4
(120)
2-7/8
(73)
2-3/16
(107)
39-15/16 (1015)
44-11/16 (1135)
1-9/16 (39)
2-1/8 (54)
4-1/2 (114)
2-5/8 (66)
1-1/4 (32)
7/8 (21.8)
27-9/16 (700)
7/8 (21.8)
1-9/16 (40)
6-5/8 (168)
9-7/16 (240)
11-1/16 (281)11-1/8 (283)
6-11/16
(170) 1-5/16 (34)
9-7/16 (240)
5/8 (16)
10-5/8 (270)
2-Ø3/16 (5) (hole)
(knock out hole)
Outlet
- (04-39) -
INDOOR UNITS INDOOR UNITS
