Fujitsu Airstage J-II Series User Manual

3 -7. HIGH STATIC PRESSURE DUCT TYPE

MODELS : ARUH36TLAV, ARUH48TLAV, ARUH60TLAV
ARUH36, ARUH48, ARUH60

Refrigerant pipe are
connection
Liquid ø 3/8 (9.52)

Gas ø 3/4 (19.05)

Drain hose - ø 3/4 (I.D.), ø 1-1/16 (O.D.)
Unit : in. (mm)
Front view
Top view
Side view (L)
Side view (R)
Rear view
(Drain hose)
3-7/16 (88)
2-13/16 (71)
15-3/4 (400)
12-3/4 (324)
9/16 (14)
6-1/8 (155)
P4-3/4 (120) x 2
= 9-7/16 (240)
11-5/8 (295) 1 (26)
1-1/8 (28)
42-1/2 (1080)
39-3/8 (1000)
33-15/16 (862) : Inlet dimension
33-1/2 (851) : Outlet dimension
Drain port
12-Ø1/8 (3)
4-15/16
(126)
P4-3/4 (120) x 5
= 23-5/8 (600)
41-5/16 (1050)
4-15/16
(125)
3-3/8
(85)
19-11/16 (500)
23-1/16 (585)
14-5/8 (371)
14 (356)
8-3/16 (208)
4-1/4 (108)
1-5/8 (41)
4-13/16 (123)
5-1/2 (139)
Air
Outlet dimension
Inlet dimension
- (04-41) -
