Fujitsu Airstage J-II Series User Manual


MODEL: ARUV30TLAV
ARUV30

Refrigerant pipe are
connection
Liquid ø 3/8 (9.52)

Gas ø 5/8 (15.88)

Drain port - ø 3/4 (I.D.)
Front view
Top view
Bottom view
Side view
5-3/16 (132)
3-1/2 (89)
2-11/16 (69)
3-9/16 (91)
22-3/16 (564)
23-13/16 (605)
1-1/2 (38)
11-13/16 (300)
18-7/8 (480)
1-7/8 (48)
12-1/2 (318)
21-11/16 (551)
4-7/8 (124)
5-3/16 (132)
13 (330)
16-7/16 (417)
51 (1295)
1-1/8 (28)
Unit : in. (mm)
- (04-48) -
INDOOR UNITS INDOOR UNITS
