INSTALLATION PLACE
Unit : in. (mm)
Upper air outlet
Lower air outlet
1 to 2 (20 to 30)
Indoor
unit
Grating
(Wall cap)
2 (50) or more
4 (80) or more
4 (100) or more
4 (80) or more
6 (150) or below from the floor
4 (100) or more
4 (80) or more 4 (80) or more
