PACKING LIST
Name and shape Quantity Application
DVD-ROM *
1
1
Includes the software and manuals for System Controller Lite. Both
VRF Controller and VRF Explorer software are included.
Wibu Key
(Software
protection key)
1
Software protection key to be inserted in a USB slot running System
Controller. System Controller may only run on a PC with Wibu Key.
However, Wibu key is not required for remote
VRF Explorer
software.
*
1
: DVD-ROM is not attached to OPTION (UTY-PLGXA1, UTY-PLGXR1, UTY-PLGXE1).
SOFTWARE CONFIGURATION
UTY-PLGXA1, UTY-PLGXR1, UTY-PLGXE1
WIBU-Key
UTY-ALGX
WIBU-Key
WIBU-Key
unnecessary
Option
Remote Site
(Monitoring center side)
Local Site
(VRF network system side)
VRF ExplorerVRF Controller
Any number can be installed in remote site personal computers.
System Controller Lite UTY-ALGX can be installed in the local site PCs (VRF Controller) connected to the VRF
network system and the multiple remote site PCs (VRF Explorer) connected to those computers via the Internet
or LAN. Just this single product creates the control, management, and monitoring environment for the customer’s
properties including remote operation.
* The WIBU-Key is not required for PCs on the remote site side. Some functions, such as equipment registration, and input/output, are not pos-
sible on the remote site side.
Optional software to strengthen the various function
● Electricity charge apportionment function can be added by installing optional UTY-PLGXA1.
● Remote centralized control function can be added by installing optional UTY-PLGXR1.
● Energy saving management function can be added by installing optional UTY-PLGXE1.
OTHER REQUIRED DEVICES (LOCALLY PURCHASED)
● Personal computer that satisfies the following system requirements
● Echelon® U10 USB Network Interface – TP/FT-10 Channel (Model number: 75010R)
(Required for each VRF Network.)
- (05 - 31) -
