Installation method
Setting pattern 1: Integrated type
Power
supply unit
Setting pattern 2: Separate type
Power supply
unit
Ceiling
Control panel
Wall
Wall
Extension cable
(Service parts)
Control panel
●
Integrated type
Refer to an installation manual for the details.
Transmission cable
Power supply cable
Cable Tie
One touch bush
Screw × 6 (Accessories)
Relay connector
Screw × 4
Screw
CN13
Connecting
cable
Cable Tie
Cable Tie
One touch bush
Wall hole
Switchbox
Power supply cable
- (05 - 53) -
