Fujitsu Airstage J-II Series User Manual

●
Separate type
Transmission
cable
Extension cable
(Service parts)
Holder
Screw × 2
(Accessories)
Screw
CN13
Connecting
cable
Cable Tie × 2
Cable Tie
One touch bush
× 2
Wall
Screw × 2
(Accessories)
Cutting out
(When wiring a transmission cable up
direction of the front panel)
Power unit
cover
Screw × 4
Screw × 2
Screw × 2
Screw × 2
(Accessories)
Screw × 2
(Accessories)
Ceiling
z
The diagram of the mounting plate screw hole positions
Unit: in. (mm)
1-13/16 (46) 1-13/16 (46)
3-5/16 (84)
3-7/8 (99)
3/16 (5)
2-Ø3/16 (5)
R1/8 (2.5)
5-5/16 (135)
- (05 - 54) -
CONTROL SYSTEM CONTROL SYSTEM
