DIMENSIONS
For M4x16 mm
screws
Hole pitch
(30)(25)
Hole: 2-Ø3/165
Hole: 2-Ø1/4 (7)
For code (
Ø3/165)
For code (> Ø3/165)
For code (
Ø1/4 (7))
For code (> Ø1/4 (7))
3-Ø3/16 (4.5)
3-7/8 (98)
2-Ø3/8 (10)
2-Ø5/16 (8)
4-3/4 (121) 3/8 (10)
1-11/16 (43)
Hole: 1/16 x 5/16 (2 x 8)
4-5/8 (117)
5-1/2 (140)
For open case
1-3/161
(30)
1-3/16
(25)
1
Unit: in (mm)
PACKING LIST
Name and shape Quantity Application
Installation manual 1
Cable tie 4 For xing the cables inside the control unit.
Screw 3 For mounting the control unit.
Connector 1
For connecting the cable and attaching the
board connector.
Refrigerant pressure sensor
1
For refrigerant pressure measurement.
The cable length is 5ft (1.6m).
Joint pipe 1
For attaching the refrigerant pressure sensor
to the refrigerant pipe.
- (05 - 104) -
CONTROL
SYSTEM
CONTROL
SYSTEM
