WIRING SPECIFICATIONS
Use Size Cable type Remarks
Power cable (using
remote control
cable)
16 to 22 AWG
(0.33 to 1.25 mm²)
Non-polar 2 core, twisted
pair sheathed PVC cable
Maximum cable length:
32ft (10m)
Transmission cable
22 AWG
(0.33 mm²)
22AWG LEVEL 4 (NEMA)
non-polar 2core, twisted
pair solid core diameter
0.65mm
L
ON
W
ORKS
®
compatible
cable
: Use shielded cable in accordance with local rules for remote controller cable.
NOTE:
Select a exible cable that can be bound using cable ties from over the cable sheath inside this product.
● Maximum connectable number of remote controllers by cable size and length:
Cable size Maximum connectable number of remote controllers
AWG mm² L* ≤ 100 m 100 m < L* ≤ 250 m 250 m < L* ≤ 500 m
16 1.25 2 2 2
18
0.75
(1.25 > S* ≥ 0.75)
2 2
20
0.5
(0.75 > S* ≥ 0.5)
2
Prohibited
22
0.3
(0.5 > S* ≥ 0.3)
2
NOTE:
Cable size and length conditions within the remote controller group this product is connected:
Size and length of the cable connected to this product should be included.
- (05 - 105) -
CONTROL
SYSTEM
CONTROL
SYSTEM
