CONTROL AND MONITORING ITEMS WITH OBJECT TYPES
NOTE:
For detailed information, check the Instruction Manual.
Function Name
Category
Bacnet Object
Type
1
Remark
Target Monitor Control
Operation Setting Bat - ○ BO
Operation Mode Bat - ○ MO
Temperature Setting Bat - ○ AO
Fan Speed Bat - ○ MO
R/C Prohibition Bat - ○ MO
Gateway GW ○ - D No monitor/control di󰀨erence
Representative Error GW ○ - BI Gateway, Lon communication
Error Code GW ○ - MI
Gateway, Lon communication.
Error Codes to signal gateway status
will be agreed with FGL during
development.
Energy Saving Status / Setting GW ○ ○ BI / BO
Existence Check In ○ - BI
Temperature Status / Setting In ○ ○ AI / AO
Operation Status / Setting In ○ ○ BI / BO
Operation Mode Status /
Setting
In ○ ○ MI / MO
Fan Speed Status / Setting In ○ ○ MI / MO
Suction/Room Temperature In ○ - AI
Representative Error In ○ - BI
Error Code In ○ - MI
Temperature H/L Limit Status
/ Setting
In ○ ○ AI / AO
H/L limit per 3 operation Mode:
HEAT, COOL-DRY and AUTO
Temperature Limit Validity
Status / Setting
In ○ ○ BI / BO
Filter Sign Status / Reset In ○ ○ BI / BO Only reset for control
Forced Thermo O󰀨 Status /
Setting
In ○ ○ BI / BO
Emergency Stop In ○ - BI
R/C Prohibition Status /
Setting
In ○ ○ MI / MO
Vertical Fan Status / Setting In ○ ○ MI / MO
Horizontal Fan Status / Setting In ○ ○ MI / MO
Outdoor Unit Save Status /
Setting
Out ○ ○ MI / MO
Low Noise Operation Status /
Setting
Out ○ ○ MI / MO Monitor not supported by all
Representative Error Out ○ - BI
Error Code Out ○ - MI
Forced O󰀨 Status / Setting Out ○ ○ BI / BO
*: Bacnet Object Type
BI: OBJECT_BINARY_INPUT
BO: OBJECT_BINARY_OUTPUT
MI: OBJECT_MULTISTATE_INPUT
MO: OBJECT_MULTISTATE_OUTPUT
AI: OBJECT_ANALOG_INPUT
AO: OBJECT_ANALOG_OUTPUT
D: OBJECT_DEVICE
Notication object shall be required to support intrinsic reporting.
