To protect the compressor of the outdoor unit, carefully read and understand the following cautions that may aect
the operation of the compressor before executing the setting.
When performing periodical settings like schedule settings for the following functions, perform the setting to all the
indoor units in the same refrigerant system simultaneously, conforming to the timing restriction described below.
<Corresponding function>
More than 10 minutes must elapse
More than 10 minutes must elapse
· Stop operation
· Set indoor unit forced thermostat
o mode
· Start operation
· Release indoor unit forced
thermostat o mode
Forced thermostat OFF instruction
Only one equipment can send these instructions for each refrigerant system.
When these instructions are sent by multiple equipment, the system may not respond as instructed or may
malfunction.
SPECIFICATIONS
Power supply 1ø AC 208-240 V 50/60 Hz
Input Power (W) 4.6
Dimensions [H × W × D]: in. (mm) 2-3/8 × 10-5/8 × 6-15/16 (60 × 270 × 176)
Weight: lb. (g) 3 (1,200)
z
Recommended operating environment
Temperature: °F (°C)
Operating 32 to 114.8 (0 to 46)
Packaged 14 to 140 (-10 to 60)
Humidity (%) Packaged
0 to 95 (RH) ;
No condensation
z
Transmission specications
BACnet
®
/ IP (ASHRAE 135 Annex J)
Transmission speed 10 / 100 Mbps
Cable
Ethernet category 5 or higher STP
22AWG equivalent
Network connector RJ45
- (05 - 155) -
CONTROL
SYSTEM
CONTROL
SYSTEM
