Fujitsu Airstage J-II Series User Manual


BACnet
®
OBJECT LIST
z
Type : Indoor
Object
name
Code (II) Function
Unit
Inactive Active
Text-1 Text-2 Text- 3 Text- 4 Tex t- 5 Text-6
AI
10 Set temp. status °F
11 Space temp. °F
12 Auto temp. (Low limit status) °F
13 Auto temp. (High limit status) °F
14 Cool/Dry temp. (Low limit status) °F
15 Cool/Dry temp. (High limit status) °F
16 Heat temp. (Low limit status) °F
17 Heat temp. (High limit status) °F
AO
10 Temp. setting °F
11 Auto temp. (Low limit setting) °F
12 Auto temp. (High limit setting s) °F
13 Cool/Dry temp. (Low limit setting ) °F
14 Cool/Dry temp. (High limit setting ) °F
15 Heat temp. (Low limit setting ) °F
16 Heat temp. (High limit setting ) °F
AV
10 ECA *
1
operation data
BI
10 Operation status OFF ON
14 Filter sign status Unsigned Signed
15 Indoor unit error status Normal Fault
16 Antifreeze operation status Reset Set
17 SAVE operation status Normal SAVE
18 Forced thermostat o󰀨 status Reset Set
19 Emergency stop status Normal Stop
20 Mode mismatch status Normal Mismatch
21 Protect antifreeze status Reset Set
22 Temp. limit enable status Disable Enable
BO
10 Operation setting OFF ON
14 Filter sign resetting Reset Not reset
15 Antifreeze operation setting Reset Set
16 SAVE operation setting Reset Set
17 Forced thermostat OFF setting Reset Set
18 Emergency stop setting Reset Set
19 Temp. limit enable setting Disable Enable
MI
10 Operation mode status Cool Heat Fan Dry Auto
11 Fan speed status Low High Med Auto
12 Indoor unit error code Refer to FGL original error code
13 R.C. prohibition status Refer to R.C. prohibition setting chart
14 Vertical airow direction status 1 2 3 4 Swing
15 Horizontal airow direction status 1 2 3 4 5 Swing
16 Special driving status Normal Defrost Oil
Recovery
17 Managed mode None Master Slave Outer
MO
10 Operation mode setting Cool Heat Fan Dry Auto
11 Fan speed setting Low High Med Auto
12 R.C. prohibition setting Refer to R.C. prohibition setting chart
13 Vertical airow direction setting 1 2 3 4 Swing
14 Horizontal airow direction setting 1 2 3 4 5 Swing
TL
10 ECA *
1
operation data log
*
1
) ECA: Electricity Charge Apportionment
- (05 - 167) -
