Fujitsu Airstage J-II Series User Manual

z
Type : Outdoor
Object
name
Code
(II)
Function
Unit
Inactive Active
Text-1 Tex t-2 Text-3 Text- 4 Text-5 Tex t-6 Text-7 Tex t- 8
BI
30
Outdoor unit error status
Normal Fault
31
Forced OFF status
Reset Set
BO 30
Forced OFF setting
Reset Set
MI
30
Outdoor unit priority
operation status *
1
Cool Heat Neutral None
31
Outdoor unit error code
Refer to FGL original error code
32
Capacity Save Status
Not Set 100% 90% 80% 70% 60% 50% 40%
33
Outdoor low noise
operation status *
2
MO
30
Outdoor low noise
operation setting*
3
Stop
Level-1
Quiet
Level-1
Ability
Level-2
Quiet
Level-2
Ability
32
Capacity Save Setting
Not Set 100% 90% 80% 70% 60% 50% 40%
*
1
) Priority operation status is for Heat Pump type VRF
In other types of systems, this status is not necessary.
*
2
) Refer to the "Outdoor unit low noise operation value table" for the texts used with the "Outdoor low noise operation
status"
*
3
) Outdoor unit rmware may need to be updated for this function to work.
Contact your local sales company for detail.
z
Type : Gateway
Object
name
Code (II) Function
Unit
Inactive Active
Text-1 Text-2 Text- 3 Text- 4 Tex t- 5 Text-6
Device
- Device information
BI
00 LON Network Adaptor error status
Normal Abnormal
01 Gateway error status
Normal Abnormal
02 ES Status
Not Used
Energy
Saving
BO
02 ES Setting
Not Used
Energy
Saving
MI
00 LON Network Adaptor unit error code
Refer to FGL original error code
01 Gateway error code
Refer to FGL original error code
02 ECA *
4
status
Disable
Disable
(Stop)
Include
Indoor
Unit Only
Exclude
Indoor
And RB
Unit
Include
Indoor
And RB
Unit
Include
RB Unit
Only
MO
01 ECA *
4
setting
Stop
Include
Indoor
Unit Only
Exclude
Indoor
And RB
Unit
Include
Indoor
And RB
Unit
Include
RB Unit
Only
Notication
00-99 Notication class
CAL
00 Calendar “Holiday-1”
01 Calendar “Holiday-2”
02-31 Calendar “Special day-1” - ”Special
day-30”
Schedule
00-99 Schedule timer
*
4
) ECA: Electricity Charge Apportionment

To protect the compressor of the outdoor unit, carefully read and understand the following cautions that may a󰀨ect the
operation of the compressor before executing the setting.
- (05 - 168) -
