PACKING LIST
Name and shape Quantity Application
WHITE-USB-KEY
(software protection key with software)
1
Includes the software and manuals for Web Monitoring Tool.
Additionally, it works as the software protection key.
Software protection key to be connected to an USB port on the PC
that the Web Monitoring Tool is installed. Web Monitoring Tool runs
only on a PC with this WHITE-USB-KEY.
OTHER REQUIRED DEVICES (Locally purchased)
● Personal computer that satisfies the following system requirements
● Echelon
®
U10 USB Network Interface – TP/FT-10 Channel (Model number: 75010R) (Required
for each VRF Network.)
SYSTEM REQUIREMENTS
●
For VRF System Side PC
Operating system
•Microsoft® Windows® 7 Professional (32-bit or 64-bit) SP1
•Microsoft® Windows® 8.1 (32-bit or 64-bit) Pro
•Microsoft® Windows® 10 (32-bit or 64-bit) Pro
CPU 1 GHz or higher
Memory • 1 GB or more (Windows® 7, 8.1, 10 [32-bit])
• 2 GB or more (Windows® 7, 8.1, 10 [64-bit])
HDD 40 GB or more of free space
Display 1,366 × 768 or higher resolution
Interface
USB port (for U10 USB Network Interface Max.4, software protection key)
Either of the following interface is required for remote connection:
• Internet using LAN: Ethernet port is required
Software Adobe
®
Reader
®
9.0 or later
Internet transmission
rate (in remote access)
Internet environment capable for communication speed of 3 Mbps or more (for
uploading) all the time (including when accessing to oversea website)
●
For Remote Side PC
Web browser Internet Explorer®11.0 or Microsoft Edge
Display 1,366 × 768 or higher resolution (Set the resolution before use so that the
resolution of Remote Side PC monitor screen is higher than that of VRF System Side
PC.)
Internet transmission
rate(in remote access)
Internet environment capable for communication speed of 4 Mbps or more (for
downloading) all the time (including when accessing to oversea website)
- (05 - 195) -
