CIRCULAR FLOW CASSETTE TYPE
Name and shape Q'ty Application
Operating
manual
1
Installation
manual
1
Cable tie (Large)
4
For xing the connection
pipe (Large and Small)
Push mount cable tie
1
For transmission and
remote controller cable
binding.
Coupler heat insulation
(Small)
1
For indoor side pipe joint
(Liquid pipe)
Coupler heat insulation
(Large)
1
For indoor side pipe joint
(Gas pipe)
Name and shape Q'ty Application
Template (Carton top)
1
For installing indoor unit.
Washer
8
For installing indoor unit
Insulation
1
For installing drain pipe
Drain hose assy
1
For installing drain pipe
Hose band
1
For installing drain hose
Drain pipe
insulation
1
For installing drain pipe
- (06 - 68) -
