Fujitsu Airstage J-II Series - Page 642

Name and shape Q'ty Application
Tapping screw
5
For wall hook bracket
installation
Cloth tape
1
For indoor unit
installation

WALL MOUNTED TYPE
z
Models : ASUA4, 7, 9TLAV1
Name and shape Q'ty Application
Operating
manual
1
Installation
manual
1
Wall hook bracket
1
For indoor unit
installation
Name and shape Q'ty Application
Cloth tape
1
For indoor unit
installation
Seal A
1
It is used when the
diameter of gas pipe
is Ø12.70 or more
It is necessary when
using AS14
Air cleaning lter
2
For installation, refer to
the “CLEANING
AND CARE” in the
operating manual
Air cleaning lter frame
2
z
Models : ASUA12, 14TLAV1
Name and shape Q'ty Application
Operating
manual
1
Installation
manual
1
Wall hook bracket
1
For indoor unit
installation
Tapping screw
5
For wall hook bracket
installation
