HEATING CAPACITY
TC : Total Capacity kBtu/h.
IP : Input Power kW (Compressor + Outdoor fan motor).
The data is based on the following conditions. Pipe length : 25 ft. (7.5 m) , Height di󰀨erence : 0 ft. (0 m).

MODEL : AOU60RLAVM
z
Capacity : 66 kBtu/h (5 ton)
Total rated
cooling capacity
of indoor unit
Outdoor temperature
Indoor temperature
61°FDB 64°FDB 68°FDB 70°FDB 72°FDB 75°FDB 79°FDB
(°FDB)
(°FWB) TC IP TC IP TC IP TC IP TC IP TC IP TC IP
85.8
(130%)
-4.0
-5.3
40.8 3.70 40.8 3.81 40.8 3.97 40.8 4.04 40.8 4.12 40.8 4.24 40.8 4.39
5.0
3.2
46.4 3.87 46.4 4.00 46.3 4.18 46.3 4.27 46.3 4.35 46.2 4.48 46.2 4.66
10.4
8.6
50.4 4.02 50.3 4.16 50.2 4.34 50.1 4.43 50.1 4.53 50.0 4.67 49.9 4.85
15.8
14.0
55.0 4.11 54.9 4.25 54.7 4.44 54.7 4.54 54.6 4.63 54.5 4.78 54.3 4.97
17. 0
15.0
56.9 4.10 56.7 4.25 56.6 4.44 56.5 4.53 56.4 4.63 56.3 4.77 5 6.1 4.96
23.0
21.2
59.7 4.24 59.6 4.38 59.4 4.58 59.2 4.68 59.1 4.77 59.0 4.92 58.7 5.12
26.6
24.8
61.5 4.29 61.3 4.43 61.1 4.63 61.0 4.73 60.9 4.82 60.7 4.97 60.4 5 .17
30.2
28.4
64.5 4.38 64.3 4.53 6 4.1 4.73 63.9 4.82 63.8 4.92 63.6 5.07 63.3 5.27
32.0
30.2
64.8 4.45 64.6 4.60 64.3 4.80 64.2 4.90 64.0 5.00 63.8 5.15 63.5 5.35
35.6
33.8
67. 2 4.60 66.9 4.75 66.6 4.95 66.5 5.05 66.3 5.15 6 6 .1 5.30 65.8 5.50
41.0
39.2
71.8 4.83 71.6 4.98 71.2 5.18 71.1 5.28 70.9 5.38 70.7 5.54 70.3 5.74
47.0
43.0
75.2 4.99 74.9 5.15 74.6 5.35 74.4 5.45 74.2 5.55 74.0 5.71 70.9 5.59
48.2
46.0
77. 9 5.13 7 7.6 5.28 77.3 5.48 7 7.1 5.59 76.9 5.69 76.6 5.84 70.9 5.41
53.6
51.1
82.6 5.36 82.3 5.51 81.9 5.71 81.7 5.81 81.5 5.92 77.5 5.64 70.9 5.12
59.0
56.3
87.6 5.59 87.2 5.74 86.8 5.95 85.8 5.95 82.5 5.70 77.5 5.33 70.9 4.84
79.2
(120%)
-4.0
-5.3
40.8 3.77 40.8 3.89 40.8 4.04 40.8 4.12 40.8 4.20 40.8 4.31 40.8 4.47
5.0
3.2
46.4 3.97 46.4 4.10 46.3 4.27 46.3 4.36 46.2 4.45 46.2 4.58 46.1 4.76
10.4
8.6
50.3 4.13 50.2 4.27 50.1 4.45 50.1 4.55 50.0 4.64 49.9 4.78 49.8 4.97
15.8
14.0
54.9 4.23 54.8 4.38 54.6 4.57 54.6 4.66 54.5 4.76 54.4 4.90 54.2 5.09
17. 0
15.0
56.8 4.23 56.6 4.37 56.5 4.56 56.4 4.66 56.3 4.75 5 6.1 4.90 56.0 5.09
23.0
21.2
59.6 4.38 59.4 4.52 59.2 4.72 59.1 4.82 59.0 4.91 58.8 5.06 58.6 5.26
26.6
24.8
61.3 4.43 61.2 4.58 60.9 4.77 60.8 4.87 60.7 4.97 60.5 5 .12 60.3 5.31
30.2
28.4
64.3 4.54 6 4.1 4.68 63.9 4.88 63.7 4.98 63.6 5.08 63.4 5.23 63 .1 5.42
32.0
30.2
64.6 4.61 64.4 4.76 6 4.1 4.96 63.9 5.06 63.8 5.16 63.6 5.31 63.3 5.50
35.6
33.8
66.9 4.77 66.7 4.92 66.4 5.12 66.2 5.22 66 .1 5.32 65.9 5.47 65.5 5.66
41.0
39.2
71.5 5.01 71.3 5.16 71.0 5.36 70.8 5.47 70.6 5.57 70.4 5.72 65.5 5.34
47.0
43.0
74.9 5.18 74.6 5.34 74.2 5.54 74 .1 5.64 73.9 5.74 71.6 5.64 65.5 5.13
48.2
46.0
77. 6 5.33 77.3 5.48 76.9 5.68 76.7 5.78 76.1 5.84 71.6 5.46 65.5 4.96
53.6
51.1
82.2 5.57 81.9 5.72 81.5 5.92 79.2 5.77 76.1 5.53 71.6 5 .17 65.5 4.70
59.0
56.3
87.1 5.81 86.8 5.97 82.2 5.68 79.2 5.45 76.1 5.23 71.6 4.89 65.5 4.44
72.6
(110%)
-4.0
-5.3
40.8 3.86 40.8 3.98 40.8 4.13 40.8 4.21 40.8 4.28 40.8 4.40 40.8 4.56
5.0
3.2
46.4 4.08 46.3 4.21 46.3 4.39 46.2 4.48 46.2 4.56 46.2 4.70 46.1 4.87
10.4
8.6
50.2 4.26 50.2 4.40 50.0 4.58 50.0 4.68 49.9 4.77 49.8 4.91 49.7 5.10
15.8
14.0
54.8 4.38 54.7 4.52 54.5 4.71 54.4 4.81 54.4 4.90 54.2 5.05 5 4.1 5.24
17. 0
15.0
56.6 4.38 56.5 4.52 56.3 4.71 56.2 4.80 56.1 4.90 56.0 5.04 55.8 5.24
23.0
21.2
59.4 4.54 59.2 4.69 59.0 4.88 58.9 4.98 58.8 5.08 58.6 5.23 58.4 5.42
26.6
24.8
61.1 4.61 61.0 4.75 60.7 4.95 60.6 5.04 60.5 5.14 60.3 5.29 60.0 5.49
30.2
28.4
64.1 4.72 63.9 4.87 63.6 5.06 63.5 5.16 63.3 5.26 6 3 .1 5.41 60.0 5.47
32.0
30.2
64.3 4.80 64.1 4.95 63.8 5.15 63.7 5.24 63.5 5.34 63.3 5.49 60.0 5.36
35.6
33.8
66.6 4.97 66.4 5.12 6 6.1 5.32 66.0 5.42 65.8 5.52 65.6 5.67 60.0 5.16
41.0
39.2
71.2 5.22 70.9 5.38 70.6 5.58 70.4 5.68 69.8 5.72 65.6 5.35 60.0 4.87
47.0
43.0
74.5 5.41 74. 2 5.56 73.9 5.76 72.6 5.73 69.8 5.49 65.6 5.14 60.0 4.68
48.2
46.0
77.1 5.56 76.9 5.71 75.4 5.77 72.6 5.54 69.8 5.31 65.6 4.97 60.0 4.53
53.6
51.1
81.7 5.81 81.0 5.91 75.4 5.47 72.6 5.25 69.8 5.03 65.6 4.71 60.0 4.29
59.0
56.3
85.2 5.91 81.0 5.59 75.4 5 .17 72.6 4.96 69.8 4.76 65.6 4.45 60.0 4.05
66.0
(100%)
-4.0
-5.3
40.8 3.97 40.8 4.08 40.8 4.24 40.8 4.31 40.8 4.39 40.8 4.51 40.8 4.66
5.0
3.2
46.3 4.22 46.3 4.35 46.2 4.53 46.2 4.61 4 6.1 4.70 4 6.1 4.83 46.0 5.01
10.4
8.6
50.1 4.42 5 0.1 4.56 49.9 4.74 49.9 4.83 49.8 4.93 49.7 5.07 49.6 5.25
15.8
14.0
54.7 4.55 54.5 4.70 54.4 4.89 54.3 4.98 54.2 5.08 5 4.1 5.22 53.9 5.41
17. 0
15.0
56.5 4.55 56.3 4.70 56.2 4.89 5 6.1 4.98 56.0 5.08 55.8 5.22 54.6 5.41
23.0
21.2
59.2 4.74 59.0 4.88 58.8 5.08 58.7 5.18 58.6 5.27 58.4 5.42 54.6 5.49
26.6
24.8
60.9 4.81 60.7 4.96 60.5 5 .15 60.3 5.25 60.2 5.35 59.6 5.49 54.6 5.19
30.2
28.4
63.8 4.94 63.6 5.08 63.3 5.28 63.2 5.38 63.0 5.47 59.6 5.43 54.6 4.95
32.0
30.2
64.0 5.02 63.8 5.17 63.5 5.37 63.4 5.47 63.2 5.56 59.6 5.33 54.6 4.85
35.6
33.8
66.3 5.20 66.0 5.35 65.7 5.55 65.6 5.65 63.5 5.47 59.6 5 .13 54.6 4.67
41.0
39.2
70.8 5.48 70.5 5.63 68.5 5.61 66.0 5.39 63.5 5.17 59.6 4.84 54.6 4.41
47.0
43.0
74.0 5.68 73.6 5.81 68.5 5.38 66.0 5 .17 63.5 4.96 59.6 4.65 54.6 4.23
48.2
46.0
76.6 5.84 73.6 5.63 68.5 5.21 66.0 5.01 63.5 4.80 59.6 4.50 54.6 4.10
53.6
51.1
77. 4 5.63 73.6 5.33 68.5 4.93 66.0 4.74 63.5 4.55 59.6 4.26 54.6 3.88
59.0
56.3
77. 4 5.32 73.6 5.04 68.5 4.67 66.0 4.48 63.5 4.30 59.6 4.03 54.6 3.67
59.4
(90%)
-4.0
-5.3
40.8 4.10 40.8 4.21 40.8 4.37 40.8 4.44 40.8 4.52 40.8 4.64 40.8 4.79
5.0
3.2
46.3 4.39 46.2 4.52 46.2 4.69 46.1 4.78 4 6.1 4.87 46.0 5.00 46.0 5.18
10.4
8.6
50.0 4.61 49.9 4.75 49.8 4.93 49.8 5.03 49.7 5 .12 49.6 5.26 4 9.1 5.45
15.8
14.0
54.5 4.76 54.3 4.91 54.2 5.10 5 4.1 5.19 54.0 5.29 53.7 5.43 49.1 5.45
17. 0
15.0
56.3 4.77 5 6.1 4.91 56.0 5 .10 55.9 5.20 55.8 5.29 53.7 5.44 4 9 .1 5.35
23.0
21.2
58.9 4.98 58.7 5.12 58.5 5.32 58.4 5.41 57.1 5.51 53.7 5.40 49.1 4.93
26.6
24.8
60.6 5.06 60.4 5.21 6 0 .1 5.40 59.4 5.50 5 7.1 5.44 53.7 5.10 4 9.1 4.65
30.2
28.4
63.4 5.20 63.2 5.35 61.7 5.54 59.4 5.40 57.1 5 .19 53.7 4.86 49.1 4.44
32.0
30.2
63.6 5.29 63.4 5.44 61.7 5.52 59.4 5.30 57.1 5.09 53.7 4.77 49.1 4.35
35.6
33.8
65.8 5.49 65.6 5.64 61.7 5.31 59.4 5.10 57.1 4.90 53.7 4.59 49.1 4.19
41.0
39.2
69.7 5.71 66.2 5.41 61.7 5.01 59.4 4.82 5 7.1 4.62 53.7 4.33 49.1 3.95
47.0
43.0
69.7 5.48 66.2 5.19 61.7 4.81 59.4 4.63 57.1 4.44 53.7 4.16 4 9.1 3.80
48.2
46.0
69.7 5.30 66.2 5.03 61.7 4.66 59.4 4.48 5 7.1 4.30 53.7 4.03 49.1 3.68
53.6
51.1
69.7 5.02 66.2 4.76 61.7 4.41 59.4 4.24 57.1 4.07 53.7 3.81 49.1 3.48
59.0
56.3
69.7 4.75 66.2 4.50 61.7 4.17 59.4 4.01 57.1 3.85 53.7 3.61 4 9.1 3.29
