Fujitsu Airstage J-II Series User Manual

HEATING CAPACITY
TC : Total Capacity kBtu/h.
IP : Input Power kW (Compressor + Outdoor fan motor).
The data is based on the following conditions. Pipe length : 25 ft. (7.5 m) , Height di󰀨erence : 0 ft. (0 m).

MODEL : AOU60RLAVM
z
Capacity : 66 kBtu/h (5 ton)
Total rated
cooling capacity
of indoor unit
Outdoor temperature
Indoor temperature
61°FDB 64°FDB 68°FDB 70°FDB 72°FDB 75°FDB 79°FDB
(°FDB)
(°FWB) TC IP TC IP TC IP TC IP TC IP TC IP TC IP
52.8
(80%)
-4.0
-5.3
40.8 4.26 40.8 4.37 40.8 4.53 40.8 4.61 40.8 4.69 40.8 4.80 40.8 4.96
5.0
3.2
46.2 4.59 4 6.1 4.73 46.1 4.90 46.0 4.99 46.0 5.08 45.9 5.21 43.7 5.39
10.4
8.6
49.9 4.85 49.8 4.99 49.7 5.17 49.6 5.26 49.5 5.36 47.7 5.50 43.7 5.19
15.8
14.0
54.2 5.03 5 4.1 5.17 53.9 5.36 52.8 5.46 50.8 5.55 47.7 5.29 43.7 4.84
17. 0
15.0
56.0 5.03 55.9 5.18 54.8 5.37 52.8 5.46 50.8 5.53 47.7 5 .19 43.7 4.74
23.0
21.2
58.6 5.27 58.4 5.42 54.8 5.52 52.8 5.31 50.8 5 .10 47.7 4.78 43.7 4.37
26.6
24.8
60.2 5.37 58.9 5.52 54.8 5.21 52.8 5.01 50.8 4.82 47.7 4.52 43.7 4.13
30.2
28.4
61.9 5.52 58.9 5.36 54.8 4.97 52.8 4.78 50.8 4.59 47.7 4.31 43.7 3.93
32.0
30.2
61.9 5.54 58.9 5.26 54.8 4.88 52.8 4.69 50.8 4.50 47.7 4.23 43.7 3.86
35.6
33.8
61.9 5.33 58.9 5.06 54.8 4.69 52.8 4.51 50.8 4.33 47.7 4.07 43.7 3.71
41.0
39.2
61.9 5.03 58.9 4.77 54.8 4.43 52.8 4.26 50.8 4.09 47.7 3.84 43.7 3.51
47.0
43.0
61.9 4.83 58.9 4.58 54.8 4.25 52.8 4.09 50.8 3.93 47.7 3.69 43.7 3.37
48.2
46.0
61.9 4.68 58.9 4.44 54.8 4.12 52.8 3.96 50.8 3.80 47.7 3.57 43.7 3.26
53.6
51.1
61.9 4.43 58.9 4.20 54.8 3.90 52.8 3.75 50.8 3.60 47.7 3.38 43.7 3.09
59.0
56.3
61.9 4.19 58.9 3.97 54.8 3.69 52.8 3.55 50.8 3.41 47.7 3.20 43.7 2.92
46.2
(70%)
-4.0
-5.3
40.8 4.47 40.8 4.59 40.8 4.74 40.8 4.82 40.8 4.90 40.8 5.02 38.2 5.11
5.0
3.2
46.1 4.86 46.0 4.99 46.0 5.17 45.9 5.26 44.4 5.35 41.7 5.21 38.2 4.77
10.4
8.6
49.7 5.15 49.6 5.29 48.0 5.48 46.2 5.50 44.4 5.28 41.7 4.96 38.2 4.54
15.8
14.0
53.9 5.37 51.5 5.51 48.0 5.32 46.2 5 .12 44.4 4.92 41.7 4.62 38.2 4.23
17. 0
15.0
54.2 5.38 51.5 5.52 48.0 5.22 46.2 5.02 44.4 4.83 41.7 4.53 38.2 4.14
23.0
21.2
54.2 5.45 51.5 5.18 48.0 4.81 46.2 4.63 44.4 4.45 41.7 4.18 38.2 3.82
26.6
24.8
54.2 5.15 51.5 4.89 48.0 4.54 46.2 4.37 44.4 4.20 41.7 3.94 38.2 3.61
30.2
28.4
54.2 4.91 51.5 4.66 48.0 4.33 46.2 4.17 44.4 4.00 41.7 3.76 38.2 3.44
32.0
30.2
54.2 4.82 51.5 4.57 48.0 4.25 46.2 4.09 44.4 3.93 41.7 3.69 38.2 3.37
35.6
33.8
54.2 4.64 51.5 4.40 48.0 4.09 46.2 3.93 44.4 3.78 41.7 3.55 38.2 3.25
41.0
39.2
54.2 4.38 51.5 4.15 48.0 3.86 46.2 3.71 44.4 3.57 41.7 3.35 38.2 3.07
47.0
43.0
54.2 4.20 51.5 3.99 48.0 3.71 46.2 3.57 44.4 3.43 41.7 3.22 38.2 2.94
48.2
46.0
54.2 4.07 51.5 3.86 48.0 3.59 46.2 3.45 44.4 3.32 41.7 3.12 38.2 2.85
53.6
51.1
54.2 3.85 51.5 3.66 48.0 3.40 46.2 3.27 44.4 3 .14 41.7 2.95 38.2 2.70
59.0
56.3
54.2 3.64 51.5 3.46 48.0 3.22 46.2 3.09 44.4 2.97 41.7 2.79 38.2 2.56
39.6
(60%)
-4.0
-5.3
40.8 4.75 40.8 4.87 40.8 5.03 39.6 5 .10 38.1 5 .10 35.8 4.79 32.7 4.39
5.0
3.2
45.9 5.22 44.2 5.35 41.1 5.13 39.6 4.94 38.1 4.75 35.8 4.47 32.7 4.09
10.4
8.6
46.4 5.53 44.2 5.25 41.1 4.89 39.6 4.70 3 8.1 4.52 35.8 4.25 32.7 3.89
15.8
14.0
46.4 5.15 44.2 4.89 41.1 4.55 39.6 4.38 38.1 4.21 35.8 3.96 32.7 3.63
17. 0
15.0
46.4 5.05 44.2 4.80 41.1 4.46 39.6 4.30 38 .1 4.13 35.8 3.88 32.7 3.56
23.0
21.2
46.4 4.65 44.2 4.42 41.1 4 .11 39.6 3.96 38 .1 3.81 35.8 3.58 32.7 3.28
26.6
24.8
46.4 4.40 44.2 4.17 41.1 3.88 39.6 3.74 38.1 3.59 35.8 3.38 32.7 3.09
30.2
28.4
46.4 4.19 44.2 3.98 41.1 3.70 39.6 3.56 3 8 .1 3.43 35.8 3.22 32.7 2.95
32.0
30.2
46.4 4.11 44.2 3.90 41.1 3.63 39.6 3.50 3 8 .1 3.36 35.8 3.16 32.7 2.90
35.6
33.8
46.4 3.96 44.2 3.76 41.1 3.50 39.6 3.37 38 .1 3.24 35.8 3.04 32.7 2.79
41.0
39.2
46.4 3.73 44.2 3.55 41.1 3.30 39.6 3 .18 38.1 3.06 35.8 2.87 32.7 2.63
47.0
43.0
46.4 3.59 44.2 3.41 41.1 3 .17 39.6 3.05 3 8.1 2.93 35.8 2.76 32.7 2.53
48.2
46.0
46.4 3.47 44.2 3.30 41.1 3.07 39.6 2.96 38 .1 2.84 35.8 2.67 32.7 2.45
53.6
51.1
46.4 3.29 44.2 3.12 41.1 2.91 39.6 2.80 38 .1 2.69 35.8 2.53 32.7 2.32
59.0
56.3
46.4 3.11 44.2 2.96 41.1 2.75 39.6 2.65 3 8.1 2.55 35.8 2.40 32.7 2.20
33.0
(50%)
-4.0
-5.3
38.7 5.15 36.8 4.93 34.3 4.59 33.0 4.42 31.7 4.26 29.8 4.01 27. 3 3.67
5.0
3.2
38.7 4.83 36.8 4.59 34.3 4.28 33.0 4.12 31.7 3.97 29.8 3.73 2 7.3 3.42
10.4
8.6
38.7 4.60 36.8 4.37 34.3 4.07 33.0 3.92 31.7 3.77 29.8 3.55 27. 3 3.26
15.8
14.0
38.7 4.28 36.8 4.07 34.3 3.79 33.0 3.65 31.7 3.51 29.8 3.31 27. 3 3.03
17. 0
15.0
38.7 4.20 36.8 3.99 34.3 3.72 33.0 3.58 31.7 3.45 29.8 3.24 27. 3 2.97
23.0
21.2
38.7 3.87 36.8 3.68 34.3 3.43 33.0 3.30 31.7 3.18 29.8 2.99 2 7.3 2.74
26.6
24.8
38.7 3.65 36.8 3.47 34.3 3.24 33.0 3.12 31.7 3.00 29.8 2.82 2 7.3 2.59
30.2
28.4
38.7 3.48 36.8 3.31 34.3 3.09 33.0 2.97 31.7 2.86 29.8 2.69 27. 3 2.47
32.0
30.2
38.7 3.42 36.8 3.25 34.3 3.03 33.0 2.92 31.7 2.81 29.8 2.64 27.3 2.42
35.6
33.8
38.7 3.29 36.8 3 .13 34.3 2.91 33.0 2.81 31.7 2.70 29.8 2.54 2 7. 3 2.33
41.0
39.2
38.7 3 .11 36.8 2.95 34.3 2.75 33.0 2.65 31.7 2.55 29.8 2.40 2 7.3 2.21
47.0
43.0
38.7 2.98 36.8 2.84 34.3 2.64 33.0 2.55 31.7 2.45 29.8 2.31 27. 3 2.12
48.2
46.0
38.7 2.89 36.8 2.75 34.3 2.56 33.0 2.47 31.7 2.38 29.8 2.24 2 7.3 2.05
53.6
51.1
38.7 2.74 36.8 2.60 34.3 2.43 33.0 2.34 31.7 2.25 29.8 2.12 27. 3 1.95
59.0
56.3
38.7 2.59 36.8 2.47 34.3 2.30 33.0 2.22 31.7 2.13 29.8 2.01 27. 3 1.85
- (02 - 26) -
