z
Dual remote control switch for Wired remote controller, Simple remote
controller (Set I)
When 2 wired remote controllers are connected to the remote control group, select the.
●
Slave remote controller cannot be used for timer setting.
●
Last command is priority.
[Master] [Slave]
[Master]
SW2 OFF ON
of DIP Switch 1
SW2 OFF
of DIP Switch 1
Remote controller unit PCB When only 1 remote controller will connect,
Setting by SW 2 of DIP Switch 1 this SW 2 of DIP Switch 1 must be set OFF.
z
Dual remote control switch for Wired remote controller (Touch panel)
(Set J)
When 2 wired remote controllers are connected to the remote control group, select the [Master]
or [Slave] on the “RC Master / Slave Setting” screen.
●
Slave remote controller cannot be used for timer setting.
●
Last command is priority.
[Master] [Slave]
[Master]
z
Signal amplier address (Set K)
1
2
3
Signal amplier
(Max.8)
- (07 - 14) -
FUNCTION
SETTING
FUNCTION
SETTING
To Next Page
